1X2 8P8C TAB Down RJ45 Ethernet Jack For Printed Circuit Board

Product Categories

RJ45 Ethernet Connector [58]
RJ45 Shielded Connector [66]
RJ45 Multiple Port Connectors [3]
RJ45 Single Port [1]
RJ45 Without Transformer [114]
Cat6 RJ45 Connector [20]
RJ45 With Transformer [206]
RJ11 Jack [39]
RJ45 1X1 21.3mm TAB-DOWN [11]
RJ45 1X1 21.3mm TAB-UP [10]
RJ45 SMD [5]
RJ45 1X1 25.4mm TAB-UP [9]
RJ45 Modular Jack [36]
RJ45 1X1 33mm TAB-UP [7]
RJ45 Female Jack [9]
180 1x1 Angle Vertical /Top Entry [19]
RJ45 Lan Jack [40]
RJ45 1X1 TAB-DOWN / UP [6]
RJ45 Magnetics [26]
2 Port RJ45 [90]
RJ45 1X2 TAB-DOWN / UP [15]
RJ45 1X4 TAB-DOWN / UP [15]
RJ45 PCB Connector [22]
10 Pin RJ45 Connector [11]
RJ45+Single/Dual USB [16]
RJ45 2X1 [16]
RJ45 2X2 [7]
RJ45 2X4 [6]
Isolated Transformers [3]
RJ45 2X6 [1]
RJ45 2X8 [1]
SFP Connector RJ45 [11]
Connector Wire Harness [10]
RJ45 2.5G [10]
RJ45 5G [2]
TF SIM CONNECTOR [33]
RJ45 10G [3]
52 Series [37]
53 Series [9]
55 Series [15]
56 Series [53]
57 Series [6]
59 Series [40]
60S Series [3]
RJ45+ Single/Double USB [2]
SMD(10/100/1000M Base-T ; 2 5G/5G/10G Base-T ) Network Transformer Series [72]
DIP(10/100/1000M Base-T ; 2 5G/5G/10G Base-T ) Network Transformer Series [16]

Keyouda Electronic Technology Co.,ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Ask Lasest Price
Brand Name :	DGKYD
Model Number :	DGKYD112B002IWE1D
Certification :	RoHS/CE/FCC/CE/ISO9001/ISO14001
Price :	Negotiable
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	60000pcs per day
Delivery Time :	7-14days

Add to Cart

1X2 RJ45 8p8c Without LED TAB-Down RJ45 Network Connector

Applications:

Integrated RJ45 connector main used to :

• 10/100/1000M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,

optical transceiver,IP phone, internet set-top box,internet camera,net bridge,computer,telecommunication,

MODEM,HomePNA,DSL／ADSL and so on.

Specification

Part Number	DGKYD112B002IWE1D	Brand	DGKYD/OEM/ODM
Place of Origin	Guangdong of China	Certification	RoHS/CE/FCC/CE/ISO9001/ISO14001
Product Type	Connector-Modular	Connector Style	Jack
Jack Type	RJ45	Connector Type	Modular Jack
Latch Style	Standard	Latch	Down
Filter	With Filter	LED Option	Without LED
LED Color	No	Panel Stops	With Panel Stops
Shielded	Without metal shield	Applies To	Printed Circuit Board
Performance Speed	10/100/1000 BASE-T/TX	Suitable for welding type	Reflowsolding(Alternative).
Port Configuration	Double Port	Number of Positions	8
Jack Configuration	1 x 2	Terminals per Port	8
Shield Material	Copper Alloy preplated with Nickel	PCB Mounting Orientation	Side Entry (Right Angle)
Contact Mating Area Plating Material	Gold 6u/15u/30u/50u	Contact Base Material	Phosphor Bronze
Solder Tail Contact Plating Material	Tin-Lead over Nickel	PCB Mounting Style	Through Hole
Termination Method to PC Board	Through Hole-Press-Fit	Board Lock	With/Without Board Lock

Electrical Specifications at 25℃

．Insertion Loss:1-100MHZ -1.0dBmax

．Rturn Loss:1-30MHZ -16.0dBmin

30-60MHZ -14.0dBmin

60-80MHZ -10.0dBmin

．Cross Talk:1-30MHZ -40.0dBmin

30-60MHZ -35.0dBmin

60-80MHZ -30.0dBmin

．CMR:1-100MHZ -35dBmin

．Hi-pot:1500v AC 6S 1mA

．Turn Ratio:1CT:1CT±3%

．OCL:350uH @100KHZ 100Mv 8mA DC

1X2 8P8C TAB Down RJ45 Ethernet Jack For Printed Circuit Board
