    90 Degree Shielded 10/100 BASE-T RJ45 Ethernet Jack With Magnetic China Manufacturer

    Ask Lasest Price
    Brand Name : DGKYD
    Certification : RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
    Model Number : KRJ-146GYPLWNL
    Delivery Time : 10 days
    Payment Terms : T/T, D/P, D/A, L/C, Western Union, MoneyGram
    Supply Ability : 100K pcs/day
    Price : Please contact us to get the latest price.
    • Product Details
    • Company Profile

    90 Degree Shielded 10/100 BASE-T RJ45 Ethernet Jack With Magnetic China Manufacturer

    China manufacturer 90 degree shielded 10/100 BASE-T RJ45 Ethernet Jack with LED


    Part Number
    KRJ-146GYPLWNL
    Brand
    DGKYD/OEM/ODM
    Place of Origin
    Guangdong of China
    Certification
    ISO9001/ISO14001/CE /UL/FCC/Reach/RoHS
    Product Type 
    Connector-Modular
    Connector Style
    Jack
    Jack Type
    RJ45
    Connector Type 
    Modular Jack
    Latch Style
    Standard
    Latch
    Down
    Filter
    With Filter
    LED Option
    With LED
    LED Color
    Green & Yellow
    Panel Stops
    With Panel Stops
    Shielded
    Yes
    Applies To 
    Printed Circuit Board
    Performance Speed
    10/100/1000/10G BASE-T
    Grounding Options
    Panel Ground and PCB Ground
    Port Configuration 
    Single
    Number of Positions 
    8
    Jack Configuration
    1 x 1
    Terminals per Port
    8
    Shield Material
    Copper Alloy preplated with Nickel
    PCB Mounting Orientation 
    Side Entry (Right Angle)
    Contact Mating Area Plating Material 
    Gold 6u/15u/30u/50u
    Contact Base Material 
    Phosphor Bronze
    Solder Tail Contact Plating Material 
    Tin-Lead over Nickel
    PCB Mounting Style 
    Through Hole
    Termination Method to PC Board 
    Through Hole-Press-Fit
    Board Lock
    With/Without Board Lock
    Housing Material 
    PBT Polyester
    Housing Color
    Black
    Housing Material  Temperature
    Standard
    UL Flammability Rating 
    UL 94V-0

    90 Degree Shielded 10/100 BASE-T RJ45 Ethernet Jack With Magnetic China Manufacturer


    ► Our Service


    World’s Leader Supplier Of Integrated RJ45 Connector And Discrete Magnetic Transformers
    100% Guarantee Qualtiy
    •Manufactured Under Strict Controls.
    •100% Tested (Not Just Batch Tested)
    •DGKYD Is OEM Of FOXCONN For 6 Years
    •Successful Customer: PANASONIC/FOXCONN/HUAWEI/ZTE…
    Competitive Price And Service
    •More Competitive Price Than Pulse Tyco Halo And Amphenol
    •Delivery Time:1-2 Weeks After Orders
    •Free Samples Are Available
    •Provide New Design For Customer Requirements
    DGKYD Corporate Policy
    •The Corporate Goal Is To Achieve The Highest Level Of Customer Satisfaction
    Through Continuous Improvements In Quality, Delivery And Service
    • DGKYD Is Committed To And Expects Quality Performance From Every Employee
    • The Company Standard Is Defect-Free Products And Services
