Single Port Female RJ45 Ethernet Connector Jack with isolation filter

Ask Lasest Price
Brand Name :	DGKYD
Certification :	RoHS/CE/UL/FCC/CE/ISO9001/ISO14001
Delivery Time :	10 days
Payment Terms :	T/T, D/P, D/A, L/C, Western Union, MoneyGram
Supply Ability :	100K pcs/day
Model Number :	KRJ-134BNL
Price :	Please contact us to get the latest price.

Add to Cart

Product Details
Company Profile

Single Port Female RJ45 Ethernet Connector Jack with isolation filter

1x1 Single Port RJ45 Female Jack , LED Network Filter Port Side Entry

Part Number	KRJ-134BNL	Brand	DGKYD/OEM/ODM
Product Type	Connector-Modular	Connector Style	Jack
Jack Type	RJ45	Connector Type	Modular Jack
Latch Style	Standard	Latch	Down
Filter	With Filter	LED Option	Without LED
Shielded	Yes	Applies To	Printed Circuit Board
Performance Speed	10/100 BASE-TX	Grounding Options	Panel Ground and PCB Ground
Port Configuration	Single	Number of Positions	8
Jack Configuration	1 x 1	Terminals per Port	8
Shield Material	Copper Alloy preplated with Nickel	PCB Mounting Orientation	Side Entry (Right Angle)
Contact Mating Area Plating Material	Gold 6u/15u/30u/50u	Contact Base Material	Phosphor Bronze
Solder Tail Contact Plating Material	Tin-Lead over Nickel	PCB Mounting Style	Through Hole
Housing Material	PBT Polyester	Housing Color	Black
Operation Temperature	-40℃ to +85℃	UL Flammability Rating	UL 94V-0

Our Featured LAN Components
Below are a few of our featured products designed to meet your most demanding product needs for local area network applications.
PoE & PoE+ Chokes
Ethernet Chokes
Ethernet Connector Modules
HDBaseT Transformers
G.Fast Transformers
